KDS-171FP Kitchen Display Terminal

KDS-171FP Kitchen Display Terminal:

Rugged and Flexible Displays for KDS Workflows with Multi-OS Support

The KDS-171FP Kitchen Display Terminal is a 17″ all-in-one platform designed for kitchen display system (KDS) deployments and other demanding operational environments. It combines a rugged, purpose-built form factor with a responsive touch interface and installation-focused design, including sealed cable routing and support for optional accessories such as bump bars. The KDS-171FP is available in multiple configurations, including Windows- and Android-based options, to align with different KDS software requirements and deployment standards.

17″ All-in-One Terminal

Purpose-built for kitchen and other demanding industrial environments.

Rugged Construction

Features a robust, tempered-glass display and a fanless system enclosed in a durable metal housing.

Industrial-Grade Reliability

Built with high-quality electronic components to ensure maximum uptime and long-term stability.

Sealed Cable Design

Innovative SR (strain relief) design with female connector plugs allows for easy cable extension while maintaining a secure and sealed connection.

Multi-Platform Support

Compatible with both Android and Linux operating systems.

High-Visibility Touch Display

Bright, clear, and highly responsive touchscreen that functions reliably even with wet fingers or latex gloves.

Exceptional Resistance

Fully resistant to water, grease vapor, and food acids — ideal for high-humidity or food-prep areas.

Hygienic Design

Smooth, seamless surfaces with an edgeless construction make cleaning simple and ensure full hygiene compliance.

Optional Software

Can be equipped with Heng Yu Kitchen Display software for streamlined kitchen operations.

Accessory Compatibility

Supports optional Heng Yu bump bars for enhanced workflow control.

With durable construction, a kitchen-ready design, and flexible configuration options, the KDS-171FP Kitchen Display Terminal provides a dependable foundation for scalable KDS rollouts. Choose the platform and configuration that best fits your software environment, peripheral needs, and installation plan.

Product Specifications

Windows Operating System
Processor CPU: Intel® Celeron® Processor J6412
Frequency: Up to 2.6GHz
Memory: Supports DDR4 3200MHz, 1*non-ECC SO-DIMM Slot
Maximum Capacity: Up to 32GB
Display Controller: Intel UHD Graphics
Display Graphic Memory: 10th Gen Intel® Processors, 800MHz
Main Display Resolution: 17″ (1280 x 1024), ratio 5:4
Display Active Area: 337.92 x 270.336(mm)
Display Luminance: 250cd/m2
Display Viewing Angle (R/L/U/B): 89/89/89/89
Display Touch Panel: PCAP, USB protocol
Ethernet, Controller: Realtek GBE LAN Chip (RJ45, 10/100/1000 Mbps)
Storage, Primary: M.2 (NGFF) Key B/B+M Slot (SATA SSD, 2242/2260/2280)
I/O Interface: Main USB — 2 x USB-A 3.0, 2 x USB-A 2.0
I/O Interface: Audio — Line-Out/Mic 3.5mm Jack
I/O Interface: Serial — DB9 x 1 (Optional)
I/O Interface: LAN — RJ45 / POE+ LAN (Optional)
Options: Bumpbar BB20A / MK15F
Power Adaptor Input: Universal AC 100~240V, 50/60 Hz
Power Adaptor Output: DC +12V 5A/
Environment: Storage Temperature ~15°C ~ 55°C
Environment: Operation Temperature: ~0°C ~ 40°C
Environment: Operation Humidity 10% ~ 85%
Mounting: Standard VESA Mount 100 x 100 (mm)
Dimensions, Panel (w/o stand): 391 x 326 x 56 (mm)

Windows Operating System
Processor CPU: Intel® i3-1115G4
Frequency: Up to 4.1GHz
Memory: Supports DDR4 3200MHz, 1*non-ECC SO-DIMM Slot
Maximum Capacity: Up to 32GB
Display Controller: Intel UHD Graphics
Display Graphic Memory: Up to 48 EUs, 1.25Ghz
Main Display Resolution: 17″ (1280 x 1024), ratio 5:4
Display Active Area: 337.92 x 270.336(mm)
Display Luminance: 250cd/m2
Display Viewing Angle (R/L/U/B): 89/89/89/89
Display Touch Panel: PCAP, USB protocol
Ethernet, Controller: Realtek GBE LAN Chip (RJ45, 10/100/1000 Mbps)
Storage, Primary: M.2 (NGFF) Key M Slot (PCIe x4 SSD, 2242/2280)
I/O Interface: 2 x USB-A 3.0, 2 x USB-A2.0
I/O Interface: Audio — Line-Out/Mic 3.5mm Jack
I/O Interface: Serial — DB9 x 1 (Optional)
I/O Interface: LAN — RJ45 / POE+ LAN (Optional)
Options: Bumpbar BB20A / MK15F
Power Adaptor Input: Universal AC 100~240V, 50/60 Hz
Power Adaptor Output: DC +12V 5A/
Environment: Storage Temperature ~15°C ~ 55°C
Environment: Operation Temperature: ~0°C ~ 40°C
Environment: Operation Humidity 10% ~ 85%
Mounting: Standard VESA Mount 100 x 100 (mm)
Dimensions, Panel (w/o stand): 391 x 326 x 56 (mm)

Windows Operating System
Processor CPU: Intel® i5-1135G7
Frequency: Up to 4.2GHz
Memory: Supports DDR4 3200MHz, 1*non-ECC SO-DIMM Slot
Maximum Capacity: Up to 32GB
Display Controller: Intel Iris Xe Graphics
Display Graphic Memory: Up to 80 EUs, 1.3Ghz
Main Display Resolution: 17″ (1280 x 1024), ratio 5:4
Display Active Area: 337.92 x 270.336(mm)
Display Luminance: 250cd/m2
Display Viewing Angle (R/L/U/B): 89/89/89/89
Display Touch Panel: PCAP, USB protocol
Ethernet, Controller: Realtek GBE LAN Chip (RJ45, 10/100/1000 Mbps)
Storage, Primary: M.2 (NGFF) Key-M Slot (PCIe x 4 NVME SSD, 2242/2280)
I/O Interface: Main USB — 2 x USB-A 3.0, 2 x USB-A 2.0
I/O Interface: Audio — Line-Out/Mic 3.5mm Jack
I/O Interface: Serial — DB9 x 1 (Optional)
I/O Interface: LAN — RJ45 / POE+ LAN (Optional)
Options: Bumpbar BB20A / MK15F
Power Adaptor Input: Universal AC 100~240V, 50/60 Hz
Power Adaptor Output: DC +12V 5A/
Environment: Storage Temperature ~15°C ~ 55°C
Environment: Operation Temperature: ~0°C ~ 40°C
Environment: Operation Humidity 10% ~ 85%
Mounting: Standard VESA Mount 100 x 100 (mm)
Dimensions, Panel (w/o stand): 391 x 326 x 56 (mm)

Android Operating System
Processor CPU: ARM Rockchip RK3568, Quad-core Cortex-A55
Frequency: Up to 2.0GHz
Primary Storage: SSD, 32GB eMMC
Display Controller: Mali-G52
Main Display Resolution: 17″ (1280 x 1024), ratio 5:4
Display Active Area: 337.92 x 270.336(mm)
Display Luminance: 250cd/m2
Display Viewing Angle (R/L/U/B): 89/89/89/89
Display Touch Panel: PCAP, USB protocol
Ethernet, Controller: Gigabit Ethernet
I/O Interface: Main USB — USB-A 3.0 x 1, USB-A 2.0 x 3
I/O Interface: Audio — Line-Out 3.5mm Jack (Optional)
I/O Interface: Serial — DB9 x 1
I/O Interface: LAN — RJ45 x 2 / POE++ LAN (Optional)
Options: Bumpbar BB20A / MK15F / USB Speaker
Power Adaptor Input: Universal AC 100~240V, 50/60 Hz
Power Adaptor Output: DC +12V 5A/ Support POE++ power (Optional)
Environment: Storage Temperature ~15°C ~ 55°C
Environment: Operation Temperature: ~0°C ~ 40°C
Environment: Operation Humidity 10% ~ 85%
Mounting: Standard VESA Mount 100 x 100 (mm)
Dimensions, Panel (w/o stand): 391 x 326 x 56 (mm)

Processor CPU: Intel® Alder Lake-N Series
Number of Core: 4E
Frequency: Up to 3.60GHz
Memory: Supports DDR4 3200MHz, 1*non-ECC SO-DIMM Slot
Maximum Capacity: Up to 32GB
Display Controller: Intel UHD Graphics
Display Graphic Memory: Up to 24 EUs, 1.20Ghz
Main Display Resolution: 17″ (1280 x 1024), ratio 5:4
Display Active Area: 337.92 x 270.336(mm)
Display Luminance: 250cd/m2
Display Viewing Angle (R/L/U/B): 89/89/89/89
Display Touch Panel: PCAP, USB protocol
Ethernet, Controller: Realtek GBE LAN Chip (RJ45, 10/100/1000 Mbps)
Storage, Primary: M.2 (NGFF) Key-B/B+M Slot (SATA SSD, 2242/2260/2280)
I/O Interface: Main USB — 2 x USB-A 3.0, 2 x USB-A 2.0
I/O Interface: Audio — Line-Out/Mic 3.5mm Jack
I/O Interface: Serial — DB9 x 1 (Optional)
I/O Interface: LAN — RJ45 / POE+ LAN (Optional)
Options: Bumpbar BB20A / MK15F
Power Adaptor Input: Universal AC 100~240V, 50/60 Hz
Power Adaptor Output: DC +12V 5A/
Environment: Storage Temperature ~15°C ~ 55°C
Environment: Operation Temperature: ~0°C ~ 40°C
Environment: Operation Humidity 10% ~ 85%
Mounting: Standard VESA Mount 100 x 100 (mm)
Dimensions, Panel (w/o stand): 391 x 326 x 56 (mm)

Processor CPU: Intel® 12th i3-1215U
Number of Core: 2P4E
Frequency: Up to 4.4GHz/3.3GHz
Memory: Supports DDR4 3200MHz, 1*non-ECC SO-DIMM Slot
Maximum Capacity: Up to 32GB
Display Controller: Intel UHD Graphics
Display Graphic Memory: Up to 64 EUs, 1.10Ghz
Main Display Resolution: 17″ (1280 x 1024), ratio 5:4
Display Active Area: 337.92 x 270.336(mm)
Display Luminance: 250cd/m2
Display Viewing Angle (R/L/U/B): 89/89/89/89
Display Touch Panel: PCAP, USB protocol
Ethernet, Controller: Realtek GBE LAN Chip (RJ45, 10/100/1000 Mbps)
Storage, Primary: M.2 (NGFF) Key-M Slot (PCIe x 4 NVME SSD, 2242/2280)
I/O Interface: Main USB — 2 x USB-A 3.0, 2 x USB-A 2.0
I/O Interface: Audio — Line-Out/Mic 3.5mm Jack
I/O Interface: Serial — DB9 x 1 (Optional)
I/O Interface: LAN — RJ45 / POE+ LAN (Optional)
Options: Bumpbar BB20A / MK15F
Power Adaptor Input: Universal AC 100~240V, 50/60 Hz
Power Adaptor Output: DC +12V 5A/
Environment: Storage Temperature ~15°C ~ 55°C
Environment: Operation Temperature: ~0°C ~ 40°C
Environment: Operation Humidity 10% ~ 85%
Mounting: Standard VESA Mount 100 x 100 (mm)
Dimensions, Panel (w/o stand): 391 x 326 x 56 (mm)

Processor CPU: Intel® 12th i5-1235U
Number of Core: 2P8E
Frequency: Up to 4.4GHz/3.3GHz
Memory: Supports DDR4 3200MHz, 1*non-ECC SO-DIMM Slot
Maximum Capacity: Up to 32GB
Display Controller: Intel Iris Xe Graphics
Display Graphic Memory: Up to 80 EUs, 1.20Ghz
Main Display Resolution: 17″ (1280 x 1024), ratio 5:4
Display Active Area: 337.92 x 270.336(mm)
Display Luminance: 250cd/m2
Display Viewing Angle (R/L/U/B): 89/89/89/89
Display Touch Panel: PCAP, USB protocol
Ethernet, Controller: Realtek GBE LAN Chip (RJ45, 10/100/1000 Mbps)
Storage, Primary: M.2 (NGFF) Key-M Slot (PCIe x4 NVME SSD, 2242/2280)
I/O Interface: Main USB — 2 x USB-A 3.0, 2 USB-A 2.0
I/O Interface: Audio — Line-Out/Mic 3.5mm Jack
I/O Interface: Serial — DB9 x 1 (Optional)
I/O Interface: LAN — RJ45 / POE+ LAN (Optional)
Options: Bumpbar BB20A / MK15F
Power Adaptor Input: Universal AC 100~240V, 50/60 Hz
Power Adaptor Output: DC +12V 5A/
Environment: Storage Temperature ~15°C ~ 55°C
Environment: Operation Temperature: ~0°C ~ 40°C
Environment: Operation Humidity 10% ~ 85%
Mounting: Standard VESA Mount 100 x 100 (mm)
Dimensions, Panel (w/o stand): 391 x 326 x 56 (mm)
